A-A-52524/12
2.2 Design and construction. The seals (classes 1, 2, and 3 of CID A-A-52524) shall be designed
and constructed in accordance with figure 1.
First
A
B1
B2
Dash
Shaft
Seal
Housing
C
Number
Dia
O.D.
Bore
Width
(Ref) + .020
(Size)
(Nom)
(1)
11
1.56
2.546
2.542
.750
12
1.63
3.504
3.500
1.063
13
1.69
2.987
2.983
.734
14
1.88
3.110
3.105
.781
15
1.88
3.502
3.497
.844
16
2.25
3.255
3.250
.734
17
2.25
4.013
4.008
.844
Figure 1. Seal design, construction, and part number.
