Seal, Plain Encased: Dual Seal, External Seal Spring LoadedThis CIDSS covers seals to be used as rotary shaft seals to retain oil and other fluids.

Pages 1 - 2 - 3

A-A-52524/9

2.2 Design and construction. The seals (classes 1, 2, and 3 of CID A-A-52524) shall be designed and constructed in accordance with figure 1.

First

Dash

Number

(Size)

A

Shaft

Dia

(Nom)

B1

Seal

O.D.

(1)

B₂

Housing

Bore

(Ref)

C

Width

+ .020

11

12

13

14

15

16

17

1.75

1.88

3.13

3.44

3.63

4.75

6.63

2.506

3.193

4.755

4.820

5.003

5.755

8.006

2.502

3.188

4.750

4.815

4.998

5.750

8.000

.625

.703

.828

.750

1.031

.719

.813

Figure 1. Seal design, construction, and part number.
