A-A-52524 Seal, Plain, And Seal, Plain, Encased: Fluid, Radial, Single And Multiple Lip Sealing MemberThis commercial item description \(CID\) covers radial single and multiple lip fluid seals. The seals are intended to be press mounted as rotary shaft seals to retain oil or other fluids. The seals covered by this CID are referred to commercially as "oil seals".

Pages 1 - 2 - 3 - 4

A-A-52524A

g. Special marking, if required.

h. Selection of applicable level and packaging requirements.

7.3 Part or identification number (PIN). The PINs to be used for seals acquired to the applicable

CIDSS are created as follows:

AA 52524 XX - XXX - X

Class

1 - Leather

2 - Elastomer for normal operating temperatures

3 - Elastomer for extreme operating temperatures

4 - Mechanical- roll felt.

Size (see applicable CIDSS)

Specification sheet Number.

CID number.

CID designator.

7.4 Cross referenced data. Seals conforming to this document are interchangeable/substitutable

with seals conforming to MIL-S-45005C(AT).

MILITARY INTERESTS:

CIVIL AGENCY COORDINATING ACTIVITY:

GSA - FSS

Custodian:

Army - AT

Preparing Activity:

Army - AT

Review Activities:

Army - AR, MI

(Project 5330-1047)

DLA - IS
