INCH-POUND
AN6225 REV. 8
30 May 2008
SUPERSEDING
AN6225 REV. 7
22 October 1971
DETAIL SPECIFICATION SHEET
PACKING "V" RING HYDRAULIC
Inactive for new design after 16 December 1952
This specification sheet is approved for use by all Departments and Agencies of the
Department of Defense.
The requirements for acquiring the product herein shall consist of this specification sheet
and procurement specification MIL-DTL-5516.
NOMINAL OD
LIP OVERLAP IN OPERATION POSITION
ACTUAL LIP OD AS MOLDED
OPERATING POSITION
MANUFACTURER'S TRADEMARK AND
W
6° MIN FLARE OUT ANGLE
APPLICABLE PART NUMBER SHALL
IN MOLDED POSITION
BE MOLDED HERE IN ACCORDANCE WITH
PROCUREMENT SPECIFICATION
ID
.005 MIN FLAT, NOT
STACK
TO EXCEED L WIDTH
HEIGHT
90 ± 4°
AS MOLDED POSITION
A
A
B
OD
NOMINAL ID
HEEL CLEARANCE
ACTUAL LIP ID AS MOLDED
C
R
SHAPE OF THESE
L
SYMMETRICAL
CORNERS OPTIONAL
ABOUT C
L
90°
R .063 MAX
ENLARGED SECTION A-A
FIGURE 1. "V" Ring
AMSC N/A
FSC 5330
