MIL-DTL-16685E
Class 2
M 16685 - 2 I B
Size (see Table 1)
Type (see 1.2)
Class 2 (see 1.2)
Specification Number
Prefix for Military Specification
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this
standard. This section does not include documents cited in other sections of this standard or
recommended for additional information or as examples. While every effort has been made to
ensure the completeness of this list, document users are cautioned that they must meet all
specified requirements of documents cited in sections 3, 4, or 5 of this standard, whether or not
they are listed.
2.2 Non-Government publications. The following documents form a part of this document to
the extent specified herein. Unless otherwise specified, the issues of these documents are those
cited in the solicitation or contract.
AMERICAN SOCIETY FOR QUALITY (ASQ)
ASQ Z1.4
Sampling Procedures and tables for Inspection by Attributes.
(Copies of this document are available from www.asq.org or the American Society for
Quality, 600 North Plankinton Avenue, Milwaukee, WI 53203.)
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a
conflict between the text of this document and the references cited herein, the text of this
document takes precedence. Nothing in this document, however, supersedes applicable laws
and regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 Class 1, rounded.
3.1.1 Material.
3.1.1.1 Composition A. The fiber shall be composed of polytetrafluoroethylene (expanded
PTFE) graphite, and a high temperature lubricant. This product shall be asbestos free.
3.1.1.2 Composition B. Packing shall be composed of an admixture of cork particles,
graphite, lubricant and a plastic binder enclosed in a woven cotton lattice jacket.
3.1.2 Sizes. Packing shall be furnished in rounded cross section in sizes 1/8 (.125), 3/16
(.188), 1/4 (.250), 5/16 (.313), 3/8 (.375), 7/16 (.438), and1/2 (.500) as specified (see 6.2).
3.2 Class 2, preformed.
3.2.1 Material.
2
