MIL-PRF-1149D
TABLE I.
Tolerances in width and thickness.
Width
Tolerance
Thickness
Tolerance
(inches)
(± inch)
(inches)
(± inch)
Less than 1/16
1/100
Less than 1/16
1/128
1/16 to 1/8,
1/64
Over 1/16 to 1/8,
1/64
inclusive
inclusive
Over 1/8 to 1/2,
1/32
Over 1/8 to 1/2,
1/32
inclusive
inclusive
Over 1/2 to 1,
3/64
Over 1/2 to 1,
3/64
inclusive
inclusive
Over 1 to 2,
1/16
Over 1
1/16
inclusive
Over 2
3 percent of
width
3.3.2 Strips. The strip rubber cross section dimensions shall be as
specified (see 6.2). Unless otherwise specified, tolerances in width and
thickness shall be as specified in table I.
3.3.3 Cut, molded, and extruded shapes. Cut, molded, and extruded
shapes shall have the form, dimensions, and tolerances as specified (see 6.2).
The gasket material shall be as specified
3.4 Physical requirements.
in table II.
